350 - 1400kg Weight 200 - 500kg / h Maximum Capacity peanut powder making machine
Product Introduction :
BS peanut flour making machine is specially used for sesame, peanut and almond. Nuts with high oil content such as mustard seeds and walnut kernels.
BS is designed and developed by our company, which fills the gaps in domestic oil factories, and produces a crushing machine specially used for crushing materials with high oil content, reaching the international advanced level.
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder making machine
Working Principle :
The raw materials are fed into the cavity of the roller crusher from the hopper and crushed into powder by the roller. By adjusting the distance between the two rollers, finished products of different sizes can be obtained, and the number of crushing rollers can be added according to customer needs.
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder making machine
Technical Data e:
| Model | BS150-3 | BS150-4 | BS250-3 | BS250-4 | BS500-3 | BS500-4 |
| L(mm) | 780 | 780 | 920 | 920 | 1340 | 1340 |
| W(mm) | 670 | 670 | 720 | 720 | 1210 | 1210 |
| H(mm) | 1600 | 1850 | 1750 | 2000 | 2000 | 2250 |
| Weight (kg) | 350 | 520 | 580 | 750 | 1200 | 1400 |
| Capacity(kg/h) | 50-200 | 50-200 | 100-400 | 100-400 | 200-500 | 200-500 |
| Motor(kw) | 2.2 | 3 | 5.5 | 7.5 | 11 | 15 |
| Roller diameter(mm) | ϕ150 | ϕ150 | ϕ150 | ϕ150 | ϕ219 | ϕ219 |
| Roll length(mm) | 150 | 150 | 250 | 250 | 500 | 500 |
| Roller speed(r/min) | / | Driving wheel:33 | / | Driving wheel:33 | / | Driving wheel:33 |
| / | Passive wheel:18 | / | Passive wheel:18 | / | Passive wheel:18 |
| Driving wheel:33 | Driving wheel:42 | Driving wheel:33 | Driving wheel:42 | Driving wheel:33 | Driving wheel:42 |
| Passive wheel:18 | Passive wheel:22 | Passive wheel:18 | Passive wheel:22 | Passive wheel:18 | Passive wheel:22 |
| Driving wheel:42 | Driving wheel:48 | Driving wheel:42 | Driving wheel:48 | Driving wheel:42 | Driving wheel:48 |
| Passive wheel:22 | Passive wheel:26 | Passive wheel:22 | Passive wheel:26 | Passive wheel:22 | Passive wheel:26 |
| Driving wheel:48 |
| Passive wheel:26 |
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder making machine
Detailed Images :
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder making machine
Applicable :
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder making machine
For nuts materials, we have different machines to do different processing, into powder or paste, of course, for the material washing, baking process, later feeding, packaging and other steps, we also have the corresponding machine can provide.
peanut powder making machinepeanut powder making machinepeanut powder making machinepeanut powder Please contact us if you have interests in our products.
